Material selection and troubleshooting of double-layer glass reactor
As a professional, it is very important to master the selection method and troubleshooting method of the double glass reactor. let us see.
Double glass reactor selection method:
1. The materials used in the double-layer glass reactor (G3.3 borosilicate glass) have excellent material and chemical properties. In the mixing process of variable frequency speed regulation, it runs smoothly, and even if the torque is large, no spark will be generated.
2. In addition, the parts are sealed with PTFE, which maintains a good vacuum (generally around -0.095 MPa) in the same product on the market, and maintains high-precision sealing under working conditions. There is also a debris collection box.
3. Teflon discharge valve, movable interface, completely exhausted.
4. After the reaction is completed, the cooling or heating solution of the double-layer glass reactor interlayer can be completely discharged without liquid accumulation.
5. The overall stainless steel column movable frame structure, five reactor covers, with a full set of glass such as reflow, liquid addition, temperature measurement.
6. Double-tetrafluoroethylene stirrer for double glass reactor is suitable for mixing and mixing low to high viscosity liquids.
7. Alloy steel mechanical seal, PTFE joint, keep high precision seal under working condition.
8. PT100 sensor probe has high temperature measurement accuracy and small error, which effectively improves work efficiency.
Simple troubleshooting method for double glass reactor:
(1) Turn on the power switch, the indicator light does not light: If the external power supply is not connected or the contact is poor, please check the power supply and the socket with a professional electrician.
(2) The power indicator light is on, but it does not turn: the shaft is rusted, stop using, and contact the supplier. Motor, electrical box failure, not connected to the seven-pin plug, reconnect the seven-pin plug;
(3) The vacuum suddenly disappears: the glass has cracks, the switch is broken, the glass parts are inspected, and the switch is replaced;
(4) There is vacuum, but it cannot be pumped out: the seal ring is worn. If the vacuum switch leaks, please replace the seal ring and switch;
(5) Sometimes it is not vacuum: the steel shaft and the dirt joint are loose, please clean the dirt and check the vacuum gauge and vacuum pump;
(6) Vacuum hose aging: Please replace the vacuum hose.
(7) Fuse short circuit: Place the power switch in the off position and replace the fuse.
