When the glass reactor is used, it is injected into the constant temperature hot-dissolving medium or cooling medium through the interlayer, and the material in the reaction kettle is heated or cooled at a constant temperature, and can be stirred, the material is reacted in the reaction kettle, and the reaction solution can be controlled. Evaporation and reflux, the reaction is completed, the material can be discharged from the discharge port at the bottom of the kettle, and the operation is very convenient.



When operating the equipment, you need to turn on the power switch first, then let the machine run from slow to fast. When the machine is stopped, the machine should be stopped. Then turn off the switch. Install the machine first and then be wired by a professional electrician. Within 5 minutes of the power supply, there is a possibility of electric shock due to the discharge of the inverter or capacitor. The interfaces of the glass reactor should not be tightened too tightly. It is necessary to loosen the activity regularly to avoid the long-term tight locking and cause the connector to bite. The PTFE switch can not be tightened excessively and easily damage the glass.



Check the glass reactor carefully before use, whether the glass bottle is damaged, whether the interfaces are consistent, pay attention to light handling, and when repairing or inspecting the glass reactor, be sure to cut off the power supply and water source, indicating that the equipment is fragile. Users, please be careful when using the product. Regularly clean the seal by removing the seal and checking for dirt on the shaft. Wipe it off with a soft cloth, then apply a little vacuum grease and reinstall it to keep the shaft and seal slipper.



Every time you use it, you must wipe off all kinds of oil stains, stains, and solvent left on the surface of the machine with a soft cloth to keep it clean. After the shutdown, loosen the PTFE switch, and the long-term stationary state will deform the PTFE piston.

The method used in the glass reactor:



1. pay attention to the relevant inspection of the power supply voltage used, must be consistent with the specifications provided on the machine nameplate, otherwise there will be problems in use. When the plug of the power supply is plugged in, this time must be turned on to turn on the power switch on the inverter. As for its speed, you can use the speed control button to determine the speed.



2.during operation, when the flow of material or the speed of the motor is concentrated at a certain point, the resonance will occur. At this time, it is necessary to pay attention to changing the motor speed to avoid the occurrence of resonance. To avoid such a situation, be sure to take care not to leave the operator's control when using it.



3. After the stir bar is installed, be sure to rotate it by hand before use. At this time, it is the problem of concentricity. If there is a problem with the concentricity, then the heavy clamp should be loosened and then made. The clip is being processed and the power is turned on again.



4. In the process of use, attention should be paid to the sealing of the glass reactor. If the performance of the seal is gradually decreasing, the rotary bearing in the agitator should be inspected. Of course, in the process of use, there will be some temporary use problems, and it is necessary to perform the shutdown check in time.



The main contents of the maintenance work of the glass reactor are:



1. In order to ensure the normality of the glass reactor, it is necessary to pay attention to the support of the reactor during installation. It should be carried out by using the ear seat and the bottom support. The reaction vessel should not be lifted through the manhole or the clamp, because this will cause It is damaged or damaged. Also, once it is fixed, do not lift or move it. Because uneven lifting forces can damage the equipment, we should avoid this problem.



2. If the heat dissipation of the device is found to be insufficient, then it indicates that there is a problem. At this time, it is necessary to check whether the condenser matches the host. If it does not match, it should be processed in time. In addition, we can also rinse the condenser fins with water, but this can not be used for a long time, because the time is long, it is easy to cause scale on the condenser fins, but it will affect its heat exchange capacity and effect.



3. The finned tubes should be thoroughly cleaned and finished to ensure that they are clean and neatly arranged. The condenser should be thoroughly inspected, is it intact, can work normally, and should be disposed of in time if there is any problem.



4. When cleaning, users should pay attention to the use of acidic cleaning agents, should use alkaline, in order to achieve cleaning purposes.



The maintenance of the glass reactor vessel is an important skill. The maintenance of the equipment is directly related to the service life of the equipment and the working efficiency of the use. Therefore, we must do the maintenance work in daily life.



We need to do the cleaning and maintenance work when using the glass reactor equipment. So, what do we need to pay attention to when cleaning up?

Glass reactor cleaning and maintenance work



1. Check the instrument carefully before use. Whether the glass bottle is damaged or not, and whether the interfaces are consistent, pay attention to light handling.



2. When making any repairs or inspections on the glass reactor, be sure to cut off the power supply and water source.



3, the electrical part must not enter the water, it is strictly prohibited to get wet.



4. Wipe each interface with a soft cloth (can be replaced with a napkin) and apply a small amount of vacuum grease. The vacuum grease must be covered after use to prevent the entry of lime sand.



5. The interfaces of the glass reactor should not be tightened too tightly. It should be loosened regularly to avoid the long-term tight lock and cause the connector to bite.



6. Turn on the power switch first, then let the machine run from slow to fast. When the machine stops, stop the machine and turn off the switch.



7, the PTFE switch everywhere can not be tightened too much, easy to damage the glass.



8, must purchase the original authentic accessories, free use of other accessories can cause fatal damage to the machine.



9. Loosen the PTFE switches after the machine is stopped. The long-term stationary state will make the PTFE piston deform.



10. Regularly clean the sealing ring by removing the sealing ring and checking if there is dirt on the shaft. Wipe it with a soft cloth, then apply a little vacuum grease and reinstall it to keep the shaft and seal ring smooth.



11. Every time you use it, you must use a soft cloth to clean all kinds of oil traces left on the surface of the machine, stains, solvent remaining, and keep it clean.
